AMM-1221 Digital Multimeter

AKTAKOM AMM-1221 digital multimeter provides precision measurement accuracy (up to 0.1%) and wide functionality at an affordable price. Large LCD display with backlight: 4 1/2 digits, 22000 counts. TrueRMS measurements: 40 Hz to 10 kHz. Basic accuracy 0.1%. Input impedance ≥10 MΩ. Measurement speed 2 times/s.

AKTAKOM AMM-1221 digital multimeter provides precision measurement accuracy (up to 0.1%) and wide functionality at an affordable price. Due to the capability of TrueRMS measuring AMM-1221 multimeter correctly measures non-sinusoidal signals at 40 Hz to 10 kHz frequency range.

In addition to the usual measuring functions for portable multimeters AMM-1221 multimeter is capable of measuring duty cycle and temperature (using K-type thermocouple).

Main features:

  • Large LCD display (69 x 52 mm) with backlight: 4 1/2 digits, 22000 counts
  • TrueRMS measurements (40 Hz...10 kHz)
  • Basic accuracy 0.1%
  • Input impedance ≥10 MΩ
  • Measurement speed 2 times/sec
  • Analog scale 45 segments
  • Automatic and manual range selection
  • Hold current values
  • Recording maximum and minimum values
  • Relative measurement mode
  • Diode and continuity test
  • Low battery indicator
  • Auto power off (30 min)
  • Overload protection 1000 V, CATIII

    Specifications:

    DC voltage

    Ranges Best resolution Accurancy
    220,00 mV 0,01 mV (0,1%+5 digits)
    2,2000 V 0,1 mV (0,1%+2 digits)
    22,000 V
    0,001 V
    220,00 V
    0,01 V
    1000,0 V 0,1 V (0,1%+5 digits)

    AC voltage (4010000 Hz)

    Ranges Best resolution Accurancy
    220,00 mV
    0,01 mV ≤1kHz
    (1,0%+10 digits)
    >1 kHz (1,5%+50 digits)
    2,2000 V
    0,1 mV
    ≤1kHz (0,8%+10 digits)
    >1 kHz (2,0%+50 digits)
    22,000 V
    0,001 V ≤1kHz (0,8%+10 digits)
    >1 kHz (2,0%+50 digits)
    220,00 V
    0,01 V ≤1kHz
    (0,8%+10 digits)
    >1 kHz (2,0%+50 digits)
    750,0 V 0,1 V ≤1kHz (1,2%+10 digits)
    >1 kHz
    (3,0%+50 digits)

    DC current

    Ranges Best resolution Accurancy
    220,00 A
    0,01 A
    (0,5%+10 digits)
    2200,0 A
    0,1 A
    22,000 mA
    0,001 mA
    220,00 mA 0,01 mA (0,8%+10 digits)
    20,00 A*
    0,01 A (2,0%+25 digits)

    AC current (4010000 Hz)

    Ranges Best resolution Accurancy
    220,00 A
    0,01 A
    ≤1kHz
    (0,8%+10 digits)
    >1 kHz (1,2%+50 digits)
    2200,0 A
    0,1 A ≤1kHz
    (0,8%+10 digits)
    >1 kHz
    (1,2%+50 digits)
    22,000 mA
    0,001 mA ≤1kHz
    (1,2%+10 digits)
    >1 kHz (1,5%+50 digits)
    220,00 mA
    0,01 mA ≤1kHz
    (1,2%+10 digits)
    >1 kHz (1,5%+50 digits)
    20,00 A*
    0,01 A ≤1kHz
    (1,5%+10 digits)
    >1 kHz (2,0%+50 digits)

    Resistance*

    Ranges Best resolution Accurancy
    220,00 Ω
    0,01 Ω (0,5%+10 digits)
    2,2000 kΩ 0,0001 kΩ
    22,000 kΩ 0,001 kΩ
    220,00 kΩ 0,01 kΩ
    2,2000 MΩ 0,0001 MΩ (0,8%+10 digits)
    22,000 MΩ
    0,001 MΩ
    (1,5%+10 digits)
    220,0 MΩ 0,1 MΩ
    (5,0%+10 digits)

    Capacity

    Ranges Best resolution Accurancy
    22,000 nF
    0,001 nF
    (3,0%+5 digits)
    220,00 nF 0,01 nF
    2,2000 F 0,0001 F
    22,000 F
    0,001 F
    220,00 F
    0,01 F
    2,2000 mF
    0,0001 mF
    (4,0%+10 digits)

    Frequency*

    Ranges Best resolution Accurancy
    22,00 Hz
    0,01 Hz (0,1%+4 digits)
    220,0 Hz
    0,1 Hz
    2,200 kHz 0,001 kHz
    22,000 kHz
    0,001 kHz
    220,00 kHz
    0,01 kHz
    2,2000 МHz
    0,0001 МHz
    22,000 МHz
    0,001 МHz

    Fill factor*

    Ranges Best resolution Accurancy
    5,0% ~ 94,9% (Vrms = 1 V)
    0,1 %
    not standardized

    Temperature (K-type)

    Ranges Best resolution Accurancy
    -50 C400 C / -58F752F 1C / 33.8F not standardized

    *Please check User manual for careful measurements

  • Power: 3 V (2 AA batteries)
  • Overall dimensions 185x85x30 mm
  • Weight 320 g

Standard accessories

  • Multimeter
  • Test leads 2 pcs.
  • Alligator clips 2 pcs.
  • K-type thermocouple
  • Soft bag
  • Operational document
